Request Quotation for Special (Click Here)
Benefits
- Ergonomically designed
- Plug and play/User-Friendly
- Repeatable magnification settings
- Eye or safety glasses can be worn during use
- High Quality images with excellent resolution
- Stand alone system (No computer needed)
- Made with aerospace aluminum and cutting-edge technology
10X – 65X up to 40X – 260X (Optical Magnification with 24” Monitor)
Features
- 20″ Rake and pinion focusing track stand
- 16×9 Image aspect ratio displayed @ 60fps
- Detented zoom lens with 6.4:1 zoom ration
- Ring light provides shadow free illumination
- Parfocality throughout zoom range with exceptional depth of field
- Multiple zoom ranges available based your requirement by adding auxiliary lenses
- Auxiliary lens used to vary magnification, field of view, and working distance. (1.14” – 7.16”)
Accessories
PRO198 Video Inspection System Accessories
| Part # | ||
| VA7 | HDMI/USB 3 Converter | Imaging capture device and measurement software |
| 101-10 | .5 Auxiliary Lens | Reduce magnification and increase working distance |
| 102-10 | .75 Auxiliary Lens | Reduce magnification and increase working distance |
| 103-10 | 1.5 Auxiliary Lens | Increase magnification and reduce working distance |
| 104-10 | 2.0 Auxiliary Lens | Increase magnification and reduce working distance |
| 250-01 | Manual Stage | XY Axis stage with travel distance: 75x55mm |
| 252-01 | Adjusting Level Stage | 0-45 degree tilt stage rotates 360 degrees |
| 319-01 | LED Dual Light Pipe | Adjustable LED light attaches to track stand |
| 320-01 | LED Back Light | Back lit Illumination for stands |
