Optical System Specifications
| Optical System | Finite |
| System Optical Magnification | 8-50X |
| Expandable System Optical Magnification (Optional Parts Required) |
4-200X |
| Trinocular Optical Magnification | 0.32-2X |
| Standard Eyepiece | 10X Adjustable Eyepiece |
| Standard Objective | 1X Built-in Objective |
| System Field of View | Φ4.4-27.5mm |
| Standard Coupler | 0.4X |
| System Working Distance | 115mm |
Trinocular Zoom Body
| Body Optical System | Finite |
| Zoom Range | 0.8-5X |
| Zoom Ratio | 1:6.3 |
| Magnification Detent | 1X per pre-set stop |
| Eye Tube Angle | 45° |
76mm Track Stand
| Stand Type | Track Stand |
| Holder Adapter Type | Φ76mm Scope Holder |
| Track Length | 280mm |
