Optical System Specifications
| Optical System | Finite |
| System Optical Magnification | 6.7-45X |
| Expandable System Optical Magnification (Optional Parts Required) |
2-270X |
| Standard Eyepiece | 10X High Eyepoint Eyepiece |
| Standard Objective | 1X Built-in Objective |
| System Field of View | Φ4.9-32.8mm |
| System Working Distance | 100mm |
Binocular Zoom Body
| Body Optical System | Finite |
| Zoom Range | 0.67-4.5X |
| Zoom Ratio | 1:6.7 |
| Eye Tube Angle | 45° |
| Eye Tube Rotatable | 360° Degree Rotatable |
76mm Post Stand
| Stand Type | Post Stand |
| Holder Adapter Type | Φ76mm Scope Holder |
| Vertical Post Height | 305mm |
